Stainless Steel Hexagonal Bar Size and Theoretical Weight
| Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
| 7 × 7 | 0.337 | 19 × 19 | 2.479 | 38 × 38 | 9.916 |
| 8 × 8 | 0.44 | 20 × 20 | 2.747 | 40 × 40 | 10.988 |
| 9 × 9 | 0.556 | 21 × 21 | 3.029 | 42 × 42 | 12.114 |
| 10 × 10 | 0.687 | 22 × 22 | 3.324 | 45 × 45 | 13.906 |
| 11 × 11 | 0.831 | 24 × 24 | 3.956 | 48 × 48 | 15.822 |
| 12 × 12 | 0.989 | 25 × 25 | 4.292 | 50 × 50 | 17.168 |
| 13 × 13 | 1.161 | 26 × 26 | 4.642 | 53 × 53 | 19.29 |
| 14 × 14 | 1.346 | 28 × 28 | 5.384 | 55 × 55 | 20.774 |
| 15 × 15 | 1.545 | 30 × 30 | 6.181 | 60 × 60 | 24.723 |
| 16 × 16 | 1.758 | 32 × 32 | 7.032 | 65 × 65 | 29.015 |
| 17 × 17 | 1.985 | 34 × 34 | 7.939 | 70 × 70 | 33.65 |
| 18 × 18 | 2.225 | 36 × 36 | 8.9 | 75 × 75 | 38.629 |
HS Code: 72222000
Free Sample is Available.
Subtense × Subtense × 0.0069 = Weight (kg) per meter
Upon request of the purchaser in the contract or order, the producer’s certification that the material was manufactured and tested in accordance with this specification, together with a certified report of the test results shall be furnished at the time of the shipment.
